Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 90
Fig. 328.—Binder Chased-mortised for CeilingJoists. … Fig. 329.— Ceil-ing Joists con-nected to Binderby Fillet. Fig. 330.—Under Side of Floor with Wrought Binder. 74 CARPENTRY AND JOINERY. f which they are connected should always bethicker than the ordinary joists. A commonrule is to make the trimmers and trimmingjoists J in. thicker for each joist…
Carpentry · Joinery
