Fig. 341.—Plan of a Framed Floor, showing Girders, Binders, Joists, Trimming, etc. are notched to and supported by every joist. The binders are of rolled-iron orfourth bridging joist, which are stouter and steel 11 in. deep and 4J in. wide in thedeeper, as shown at a and b (Fig. 334). flanges and… … Framed Floors. The plan of a framed floor, 45 ft. by 26 ft.,is shown at Fig. 341. Three girders, Sup-ported at their centres by iron columns,carry the binders as shown. The sizes ofthe various members are : Girders, 14 in.by 10 in. sawn, reversed, and bolted witha f-in. rolled flitch in the centre…
