Radford's portfolio of details of building construction : a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale ... (1911)
Radford, William A., 1865-, Johnson, Bernard L, Rawson, Charles P · Chicago : The Radford Architectural Company · leaf 65
PLATE 52—DOUBLE HUNG WINDOW WITH GROUND CASINGS Skeleton frame construction in ordinary work, jamb showing ground casing (G. &). Fig. 71, Fig. 68, section through window head. Note tin section through sill. Fig. 72, isometric view of flashing to keep out the water. Fig. 69, section head and… … PIG. 74. r IT
Building · Architecture
