A catechism of the steam engine in its various applications to mines, mills, steam navigation, railways, and agriculture. With practical instructions for the manufacture and management of engines of every class (1864)

Bourne, John · New York, D. Appleton & co. · leaf 377

An illustration from A catechism of the steam engine in its various applications to mines, mills, steam navigation, railways, and agriculture. With practical instructions for the manufacture and management of engines of every class, 1864, leaf 377
valves and producingthe cut-off is complete, as shown in Jig. 72, and it operates asfollows: Motion is communicated by gearing from the crank-shaft tothe bevel wheel on the piece (d) on the end of the hub D, and iscommunicated to the spindle of the governor, which is screwedinto the socket on D. As… … WOODRUFF & BEACHS STEAM ENGINE. 361

Steam engineering · Steam-engines
