a very effectual manner. To intercept the water or oilwhich the discs thus drive out by their centrifugal action, a lightpaddle box or splash board of thin sheet brass is made to coverthe upper part of each of the discs, and an oil cup with depend-ing wick is supported by the tops of these paddle… … Double Disc Crank. Messrs. Bourne & Co. each revolution, and subsides into the cup from whence it pro-ceeds to lubricate the crank pin bearing. This is the expedientcommonly employed to oil the crank pins of direct acting EXPEDIENTS OF LUBRICATION^. 331 engines; but in the engine now described,…
