Fig. 9.—Fery spiral pyrometer which turns over a dial D, graduated in degrees centigrade, inresponse to the differential expansion and uncoiling of the springwhen radiation is concentrated upon it. In some of the instru-ments the spring is trimetallic, the thermal expansion coefficientof the…
