100. VARIABLEGEARING. SPEED OR CONE abed a, tight pulley on outside hollow shaft.^, tight pulley on inside hollow shaft. c, tight pulley on inner or solid shaft. d, loose pulley on solid shaft. a b c\ differential spur gears for three speeds. loi. TRANSMISSION OF POWER froma horizontal shaft to two… … 102. FRICTIONAL RECTILINEARMOTION, from the angular position of asheave or pulley rolling on a revolving barrelor long cylinder. A, forward motion; B, stop.The principle of the Judson railway pro-pulsion. Efficiency was increased by the use of a small truck withseveral roller pulleys. 103. VARIABLE…
