re inch upon its area,and it will lift and let out the water, until the descending columnbalances the weight of the valve; the cock / is for the purpose of blowing out any sediment which may have accumulated in the valvebox, this is done by depressing the rod g g, attached to the lever g,which is… … a pipe descends, and is connected with the suction-pipe of a pump,which may be either a bucket or force-pump; the exit valve orclack, is loaded by a weight and lever, like a safety-valve, with the sameobject as the water-valve already described, viz. that it may counteractthe pressure of the steam…
