The Civil engineer and architect's journal, scientific and railway gazette (1839)
London : [William Laxton] · leaf 80
Fig. 2.—Section showing the movement of the mass. … Reference. Fig. 1.—Section of Cliff before the explosion ; H house In winch the bat-teries were placed, F flag over the spot, T tunnel or heading, C one of thechambers, L R level of proposed railway, L W level of low water. Fig. 2.—Section showing the movement of the mass. Fig. 3.—Plan showing the…
Architecture · Civil engineering · Science
