Common-sense stair building and handrailing (1903)
Hodgson, Frederick Thomas, 1836-1919 · Chicago, F. J. Drake & Co · leaf 43
Fig. 43, Fig. 43 shows the face mould for the lower wreath,and Fig. 44 for the upper, also sections of rail andapplications of the bevels. The bevel for upper wreath is found at B, Fig. 42, asshown in the diagram, and is the same for both joints. 38 COMMON-SENSE HANDRAILING The bevels for lower… … FIRST METHOD 39 is shown at Fig. 9, which, upon examination, will befound to be of a type often found in our old colonialbuildings. We will now deal with a flight of stairs having sevenwinders forming a half circle, with flyers above and below. Fig. 45 shows the ground plan and elevation ofrisers,…
Stair building · Hand-railing
