Common-sense stair building and handrailing .. (1913)

Hodgson, Frederick Thomas, 1836- [from old catalog] · Chicago, F. J. Drake & co · leaf 124

An illustration from Common-sense stair building and handrailing .., 1913, leaf 124 — ovetails for balusters. Thetemplet marked a is made of somethin stuff, preferably zinc or hardwood.The dovetails are marked out as shown,and the intervening spaces are cut out,showing the dovetail portions solid.The templete is then nailed or screwedto a gauge block, e^ when the whole isready for… … 124 COMMON-SENSE HANDRAILING small hold over the center of the baluster. Screws ornails are then driven into the baluster as shown,through the holes in the iron. The rail is grooved tosuit the thickness of the iron bar and laid on as shown.Holes should be drilled here and there between…

Stair building · Hand-railing

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
