Q> 65 60-H.P. MERCEDES ENGINE. PART OF LEFT-HAND SIDE A7—MEIAL CASING ROUND EXHAUST IMlE B2—VERTICAL RODS TRANSMITTING MOVEMENT OK CAMS TO THE VALVES B3—PINIONS WORKING TIMING GEAR OF INLET VALVES E8—MAGNETS Eg—SPUR WHEEL DRIVING MAGNETS F—FITTING FROM WHICH EXHAUST PIPES ARE LED G—CIRCULATING… … GO-H.P. .MERCEDES CAR. VIEW OF CLUTCH, DASHBOARDAND OPERATING J.EVERS AND PEDALS F3—AIR HUMP FOR PRESSURE OX TANKS F4—SHUT-OFF VALVF. OF DO. V-,—LEVER CUTTI.NG (iUT SILENCER F6—PRESSURE GUAGE G6—GREASE CUP FOR CIRCULATING PUMP H—FLYWHEEL Hi—CASING ATTACHED TO DO. H2—LEVER TIGHTENING CLUTCH COIL…
