The complete motorist, being an account of the evolution and construction of the modern motor-car; with notes on the selection, use, and maintenance of the same; and on the pleasures of travel upon the public roads (1905)
Young, Filson, 1876-1938 · New York : McClure, Phillips & co.; London, Methuen & co. · leaf 157
ns of gearing are practically identical asto the dimensions and arrangements of their elements. Thepinions, bearings, etc., of the three sets are interchangeable.The functional difference of all three sets is brought aboutentirely by their coupling up to their respective brake-drumsand to each… … DIAGRAM (a) the one which carries the planet wheels. In the reversing gearthe inner element consists of the hollow shaft C, which is inrunning connection with the motor, while the outer elementP is in positive running connection through the shaft D withthe propellor or driving shaft of the car. The…
