), f, k. Find corresponding points on the opposite side ofthe boat, and proceed in a similar manner. B (Fig. 172) is across section through the middle of the boat; this, as well asany additional cross section, can be drawn in perspective, asshown in Fig. 173, by Prob. 34. These will enable the… … Fiff. 174 receding to the left converge towards \.V., while all thosereceding to the right converge towards V.P/, and if the boatwere floating in calm watei, these vanishing points would be onthe horizon line [20]. Fig. 175 shows the same pruiciple apjdied to^a boat in s 258 COMPLETE PERSPECTIVE…
