Models of ships and boats (1913)

Reisner, George Andrew, 1867-1942, Egypt. Maslahat al-Athar · Le Caire : Impr. de l'Institut français d'archéologie orientale · leaf 91

An illustration from Models of ships and boats, 1913, leaf 91
Fig. igg. — Profile and two sections. sides) is greater towards the stern. The deck consists of a single board (fig. 199,section G-D) set in flush with sides of boat (rail rising above) and projects beyondthe stern as far as the rail (fig. 199, section A-B, b). The two projecting ends ofrail at…

Mathaf al-Misri · Ship models -- Egypt · Boatbuilding -- Egypt · Shipbuilding -- Egypt · Egypt -- Antiquities

Internet Archive · New York University Libraries · Public Domain Mark 1.0. Free to use for anything.
