Complete perspective course : comprising the elementary and advanced stages of perspective, the projection of shadows and reflections, with exercises in theory and practice, also the practical application of perspective (1900)
Spanton, J. Humphrey (John Humphrey) · London : Macmillan and co. · leaf 47
Points.—Every vanishing point has a cor-responding measuring point. To find a measuring point for any receding horizontal line,take the distance of the eye from its corresponding vanishing point,and set it off on the horizon line. AVe will first determine the position of the measuring pointson… … \ \ . / \\ , j / / \ \ . , / , 66° li L Fig. 27 point corresponding to Y.P. Determine ]\r.P/ forsimilar manner. X.V ni a II IXTRODUCTIOX 25 Transfer both these points to the horizon line. Tlie trne length of each edge of the solid receding to theleft is ah. Set this distance off from e on the…
Perspective
