2 Portals:— Concrete 88 yds. @ $8.00=6704Barrel per lin. ft. Concrete6.2yfis. (S$8.00=$49.0 Steel 150 lbs. ^: .04= 6 6$55 6 If foundation Is depressed asshown dotted, tlien area = 172square feet. Len^lh for 20 ft. bank = 32ft. st = *24fO. Fig. 51. Figure 52 is a reinforced concrete box culvert…
