Constructive drawing. A text-book for home instruction, high schools, manual training schools, technical schools and universities (1904)
Hanstein, Herman. [from old catalog] · Chicago, New York [etc.] Keuffel & Esser co. · leaf 42
HansUivis Constructive Drauring. TANGENTIAL CIRCLES. 67.—Fig. 1.—Problem—To construct circles, D andH, that touch a given line, M N, and a given circlein point A. Solution.—Draw line H C A B through center Cand the given point of contact A; at A erect a per-pendicular to H B, intersecting M N in…
Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
