On the theory and calculation of continuous bridges (1876)
Merriman, Mansfield, 1848-1925, Making of America Project · New York, D. Van Nostrand · leaf 25
20 … 21 Each of the squares composing thistriangle represents one of the supports,and its left hand division gives the lefthand shear Sn_i, and the right hand onethe shear Sn (Fig. 3). Thus, in the girder of three spans, the triangle showsthat the first support, beginning at theleft, has on the left no…
