SUBTRACT SPEED OF BOBBIN DRIVINGGEAR FROM SPEED OF MAIN SHAFT. MULTI-PLY THIS BY THE VALUE OF THE DIFFEREN-TIAL TRAIN. SUBTRACT THIS FROM SPEEDOF MAIN SHAFT. RESULT IS SPEED OF CONEDRIVEN GEAR. 167. Expressed as a formula this would be: Speed of cone-driven gear L=A—value of train (A—G). 168. For… … Fig. 32. Daly Differential. CONE 168 sivubbing and roving. Rule for Holdsworth DifferentiaIv. SUBTRACT SPEED OF MAIN SHAFT FROMSPEED OF BOBBIN DRIVING GEAR. DIVIDETHIS BY 2. RESULT IS SPEED OF CONE DRIVENGEAR. 169. Expressed as a formula, this would be: Speed ofcone driven gfear L=i (L—A). General…
