Cotton mill processes and calculations. An elementary text book for the use of textile schools and for home study .. (1902)
Tompkins, Daniel Augustus, 1851-1914 · Charlotte, N.C., The author · leaf 93
rding to the ends up,usually 6), are laid up, each one in its own division of theplate C, that is, between the fingers. Each one thenpasses over its own spoon D. They all pass together between the bottom and toprolls. The top rolls are held down on the sliver byweights hung with stirrups, as shown.… … a t-ibe ci Q oo m bi> 8o DRAWING. Sliver leaves front roll K and passes through trum-pet M. Calender rolls P draw it through trumpet and depositit through hole in cover plate to coiler N. Coiler N revolves in the same manner as coiler oncards (24) and coils the sliver in can O. Stop notions. 65.…
Cotton manufacture
