l go out of their way to go throughiron. With a coil of wire the lines of force pass from itsN pole through the air on all sides of the coil to its Spole; they then pass through the inside of the coil andthrough the air back to the N pole. When the resist-ance to their passage through the coil is… … Fig. 94. MAGNETIC EFFECTS OF EIvECTRIC CURRENT. 75 a core. (See Study, Chapter XXII., for experi-ments.) 97. Forms of Electromagnets. Fig. 95 shows astraight, or bar elenromagnet. Fig. 96 shows a simpleform of horseshoe eleHromagnet. As this form is not easilywound, the coils are generally wound on…
