Young, George, jr, Baxter, Hubert Eugene, joint author · New York, The Macmillan Co. · leaf 305
8 X lOj The exactFig 255 c layout for each sheet is to be determined by the student.] Fixed pin- EXERCISE SHEET XLIX a The garage door shown in Fig. 255 is hung from two trolleys, pivotedat a and 6. The trolley a moves on thetrack ah, while 6 moves on be, as shownby the arrows. Determine the… … APPENDIX 289 termine the path of travel traced by the end of the rod, as the deskcloses. Also show the entire area over which any part of the rodmoves. Scale, 3 = 1 — 0 EXERCISE SHEET La Figure 257 shows the path followed by the front wheel of a motor-cycle equipped with a side car. Let .1 = 4 — 6;…
Geometry, Descriptive
