Dunkerley, Stanley, 1870- · London, New York [etc.] Longmans, Green · leaf 120
which vibrates about the centre P, the angle of vibrationbeing such that the wheel A is pushed through one-tenth of arevolution. The extremity of the arm F is attached by means ofa link to a pin placed eccentrically on the end of the engine shaft,so that for each revolution of the engine shaft the… … FiQ. no.> from 0 to 9, and through apertures in the frame the top numberon each dial may be read. Thus the reading of A will give therevolutions, that of B the tens of revolutions, and that of Chundreds of revolutions. As shown, the reading is 988. Thewheels are prevented from running back by…
Machinery, Kinematics of
