Dunkerley, Stanley, 1870- · London, New York [etc.] Longmans, Green · leaf 148
Fin. 143. A precisely identical arrangement is shown in JFig. 143, in whichthe link PB is dispensed with, and the point B actually constrainedto move in a slot, the slot being perpendicular to the stroke andopposite the mean position of the piston; the ratio of reduction Figs. 142, 143 are… … Fig. 144.
Machinery, Kinematics of
