modified constructively—to turn out bars of ellipticsection. A longitudinal and end elevation of Oldhams couplingis shown in Figs. 150, 151. The frame is represented by C, therotating shafts by B and D, and the connecting link by A, thelatter having two perpendicular projections, one on each side… … Fig. 150. Pig. 151. axes of the two shafts, then, as the motion is transmitted fromB to D, the tool T will turn the plate A into a truly ellipticalshape, shown by the chain-broken curve in the end elevation.The only difference between the elliptic chuck and the arrange-ment of Kg. 150 is that, in…
