Dunkerley, Stanley, 1870- · London, New York [etc.] Longmans, Green · leaf 199
Fio, 191. position shown in Fig. 196, that is to say, until the top stop Hcomes into contact with the pin C. The lever CD is then drawndown until the toggles become quite straight, as shown. The i88 MECHANISM. continued rotation of the wheel carries the arm DE past thecentre line (Fig. 197), and…
Machinery, Kinematics of
