Dunkerley, Stanley, 1870- · London, New York [etc.] Longmans, Green · leaf 221
cylinder isrepresented by S, and the pump cylinder by P—both being boltedto the bed-plate—and the steam-piston and pump plunger worktandem. The length of the stroke is governed by the crank arm,which is keyed to the crank shaft C at one extremity, and whichcarries a pin at its other extremity,… … and turning pair. If the crank shaft be the driver, the steamcylinder may be replaced by an additional pump. § 141. Worthingtons Direct-aetiag Pump.—A sketch of Worth-ingtons direct-acting pump is shown in-Fig. 222, in which S re-presents the steam cylinder, and P the pump cylinder—the pistonand…
Machinery, Kinematics of
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
