Dunkerley, Stanley, 1870- · London, New York [etc.] Longmans, Green · leaf 243
G is vertical, and itstravel will be equal to 2. PgG.Second Step in the Solution.—Next, imagine that the two crankarms rotate about the same axis, which, in the first place, is assumedto be in the line of stroke of the valve produced, as in Fig. 254.To find the equivalent crank, find first the… … Fio. 253. APPROXIMATE SOLUTIONS TO LINK MOTIONS. 233 with P as centre and radius equal to AC, draw a circular arc tocut the (approximate) line of stroke of 0 in H; and draw PiAiin a direction such that, the angle CPiAi is equal to HPA, and oflength such that PiAi is equal to PA sec PHPi. Adopt a…
Machinery, Kinematics of
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
