the cutter; when cutting, the blank is fixed and thecutter simply ascends. By these means the cutter behaves to theblank in exactly the same manner as is illustrated in Fig. 302; andafter one complete rotation of the blank, the teeth are properlyshaped on the latter. Fig. 348 shows a blank only… … ^/J^ Fig. 349. A detailed description of the mechanical arrangements of themachine is, perhaps, unnecessary.^ A general view of the machine isshown in Fig. 350, and a section of the cutter and blank in Fig. 351.The cutter is shown at A, the blank (with the teeth cut) at B.The cutter spindle is…
