FiQ. 66. 56 MECHANISM. … Fig. G7. driving shaft, which rides loosely upon the headstock mandrel B.To the boss of 0 is j^tached a spur pinion, D, which meshes witha wheel, E. The wheel E is attached by a hollow sleeve to a pinion I (so that E and Iride loosely over the spindleF), and I meshes with awheel or main gear, J,…
