Lodge, Oliver, Sir, 1851-1940 · London, New York, Macmillan and co. · leaf 74
therstop-cock tube, B ; and the third opening is to beplugged with a cork as soon as the whole vessel, bothinside and outside the bag, is completely full of waterwithout air-bubbles. CHAP. III.] CHARGE AND INDUCTION. 55 This is the insulated Leyden jar: the bag representsthe dielectric, and its… … FlG. 10.—Skeleton diagram of hydraulic model of a Leyden jar. necting the inner and outer coatings, will correspondto a discharger. Ordinarily, however, of course Cwill be shut. A water-pump screwed on to A will represent anelectric machine connected to inner coating; and theouter coating, B,…
Electricity
