Thomälen, Adolf, 1865-, Thomälen Adolf. Kurzes Lehrbuch der Electrotechnik. English · London, E. Arnold · leaf 283
Fig. 261 Fig. 262 The current I^, on the other hand, leads ahead of the terminal pressureby the angle <^2, where A circle is drawn on OG = F as diameter, and a chord OA drawn so asto make an angle ^^ with the diameter. OA represents the drop in the lowerbranch due to ohmic resistance, while ^G…
Electrical engineering
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
