Thomälen, Adolf, 1865-, Thomälen Adolf. Kurzes Lehrbuch der Electrotechnik. English · London, E. Arnold · leaf 375
Cfeneratnr Motor Fig- 365 113. Mesh or Delta Connection. The six wires between the generator and the motor in Figs. 364 and 365can be reduced to three by interconnecting the three phases. This can bedone in two ways; one, known as mesh connection, we shall consider … in this section, while the other, known as star connection, will be consideredin the next section. In the mesh connection the end of each phase-winding is connected tothe beginning of the next. The principle of this winding is seen very clearlyin machines which are wound so as to supply both direct…
Electrical engineering
