NG GAS ENGINE. This engine is made by Messrs. Fielding and Piatt, of theAtlas Works, Gloucester, and is constructed upon the Ottocycle. Fig. 38 shows an outside view of the engine. Thevalves, which are of the plain mitre type, are driven in theusual way from the crank shaft, by means of cams on a… … ^0 TYPES OF GAS ENGINES. engines was actuated by a cam on the side shaft. In thiscase the governor consisted of a simple dashpot and piston,the rod of which was connected to a lever working the gas Fio. 89.—InJicator Diagram from Fieldiuj and Piatts Engine, running witli nn Innd. valve. If the…
