Fig. 65. engine by moving the handles H, H so as to increase ordiminish the length of the slots A. It will be seen that themovement of the governor affects the width of the slotsthrough which the air and gas pass, while the length isindependently moved by means of the handles. An outside\iew of… … TYPES OF GAS EXGIXES. 81 For the large sizes of engines a aelf-starfcer is provided.This consists of a compressed air chamber tilled to a pressureof IGO lbs. per square inch, by means of an air pump drivenby hand or belt as and when desired. In order to start theengine, the ordinary exhaust cam is…
