Aviation engines, design - construction - operation and repair; a complete, practical treatise outlining clearly the elements of internal combustion engineering with special reference to the design, construction, operation and repair of airplane power plants; also the auxiliary engine systems, such as lubrication, carburetion, ignition and cooling. It includes complete instructions for engine repairing and systematic location of troubles, tool equipment and use of tools, also outlines the latest mechanical processes (1917)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley Publishing Company · leaf 107
five explosions. The balanceis good and power output regular. The valves are 106 Aviation Engines placed directly in the cylinder head and are operated bya common pushrod. Attention is directed to the novelmethod of installing the carburetor which supplies the mix-ture to the engine base from which… … Fig. 39.—Unconventional Six-Cylinder Aircraft Motor of Masson Design. engine is also of the air-cooled form and develops 50 H. P.and weighs 105 kilograms, or 231 lbs. The carburetor isconnected to a manifold casting attached to the engine basefrom which the induction pipes radiate to the…
Airplanes
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
