Aviation engines, design - construction - operation and repair; a complete, practical treatise outlining clearly the elements of internal combustion engineering with special reference to the design, construction, operation and repair of airplane power plants; also the auxiliary engine systems, such as lubrication, carburetion, ignition and cooling. It includes complete instructions for engine repairing and systematic location of troubles, tool equipment and use of tools, also outlines the latest mechanical processes (1917)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley Publishing Company · leaf 225
some form of jacket which confines itto the heated portions of the cylinder. COOLING BY POSITIVE WATER CIRCULATION A typical water-cooling system in which a pump isdepended upon to promote circulation of the coolingliquid is shown at Figs. 82 and 83. The radiator is car-ried at the front end of the… … 2a (^■Radiator T^-~-*-\s ■■Water Jacket
