Aviation engines, design - construction - operation and repair; a complete, practical treatise outlining clearly the elements of internal combustion engineering with special reference to the design, construction, operation and repair of airplane power plants; also the auxiliary engine systems, such as lubrication, carburetion, ignition and cooling. It includes complete instructions for engine repairing and systematic location of troubles, tool equipment and use of tools, also outlines the latest mechanical processes (1917)

Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley Publishing Company · leaf 34

An illustration from Aviation engines, design - construction - operation and repair; a complete, practical treatise outlining clearly the elements of internal combustion engineering with special reference to the design, construction, operation and repair of airplane power plants; also the auxiliary engine systems, such as lubrication, carburetion, ignition and cooling. It includes complete instructions for engine repairing and systematic location of troubles, tool equipment and use of tools, also outlines the latest mechanical processes, 1917, leaf 34
Two-Cylinder, Double Acting,Four Cycle Engine for Blast Furnace Gas Fuel Weight 600- Pounds per HorsepowerVery slow speed, made, in sizes upto 2000 Horsepower. 60+o 100 R.P.M. … Two Cylinder Opposed Gas Engine -150 +0 650Vtorsepower Sizes.500+0 600 Pounds per Horsepower. 90 to 100 R.P.M.

Airplanes

Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
