Aviation engines, design - construction - operation and repair; a complete, practical treatise outlining clearly the elements of internal combustion engineering with special reference to the design, construction, operation and repair of airplane power plants; also the auxiliary engine systems, such as lubrication, carburetion, ignition and cooling. It includes complete instructions for engine repairing and systematic location of troubles, tool equipment and use of tools, also outlines the latest mechanical processes (1917)

Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley Publishing Company · leaf 485

An illustration from Aviation engines, design - construction - operation and repair; a complete, practical treatise outlining clearly the elements of internal combustion engineering with special reference to the design, construction, operation and repair of airplane power plants; also the auxiliary engine systems, such as lubrication, carburetion, ignition and cooling. It includes complete instructions for engine repairing and systematic location of troubles, tool equipment and use of tools, also outlines the latest mechanical processes, 1917, leaf 485
Pump Drive 6ear Cam- ~-Cam ShaftDrive WormGear Pump _..-\ Cylinder- Pump Plunger- Plunger ReturnSprings … Plunger Oil Pipe Fig. 207.—Sectional Views of the Gnome Oil Pump. through slight-feed fittings by a mechanically operatedpump which is clearly shown in sectional diagrams atFig. 207. The Gnome is a considerable consumer of lubricant,the makers estimate being 7 pints an hour for the 100horse-power…
