Aviation engines, design - construction - operation and repair; a complete, practical treatise outlining clearly the elements of internal combustion engineering with special reference to the design, construction, operation and repair of airplane power plants; also the auxiliary engine systems, such as lubrication, carburetion, ignition and cooling. It includes complete instructions for engine repairing and systematic location of troubles, tool equipment and use of tools, also outlines the latest mechanical processes (1917)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley Publishing Company · leaf 488
llowed. This is about one-sixth the thickness of the average human hair, and inother parts the size must be absolutely standard, noappreciable variation being allowable. The manufacture Gnome Munosoupapc Engine 487 of this engine establishes new mechanical standards ofengine production in this… … Fig. 209.—The G. V. Gnome Monosoupape Nine-Cylinder Rotary EngineMounted on Testing Stand. in length and weighing about 97 pounds. The first opera-tion is to drill a 21A6 inch hole through the center of theblock. A heavy-duty drilling machine performs this 488 Aviation Engines
Airplanes
