r,whereas with coal this cannot be done. The position of the ejector, pipes, and feed tank hasbeen arranged with a view to securing the maximumefficiency in working and economy in construction. The essential features are : 1. Simple and reliable apparatus for raising the oil from the storage tank… … 170 EFFICIENCY OF PUMPS AND EJECTORS 3. The efficient heating of the oil, so that the highesttemperature is attained as the oil arrives atthe boiler. The oil flows from the storage tank a by means oftwo pipes, controlled by stop valves, to the 50-gallonejector d located in the adjoining chamber 6,…
