Mechanics of engineering (solids) : comprising statics and kinetics of solids, and the mechanics of the materials of construction, or strength and elasticity of beams, columns, shafts, arches, etc. : for use in technical schools (1911)
Church, Irving P. (Irving Porter), 1851-1931 · New York : Wiley ; London : Chapman & Hall · leaf 320
ght of beam being neglected). As before, the flexure is to be slight, and the forces are all perpendicular to the beam. The present problem is that in fig. 263, the beam being prismatic, supported at the ends, with a single eccentric load, P- We shall first disregard the weight of the beam itself.… … 302 MECHANICS OF ENGINBEKLNG. B^—J=0, i.e., J=R2;while from 2 (moin.)m=0 we have Sl-R^x= 0 .•.M= E,x^?hxe I These values of J and M hold good between 0 and 0, Jbeing constant, while M is proportional to x. Hence for00 the shear diagram is a rectangle and the moment diacgram a triangle. By…
Mechanics, Applied · Strength of materials
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
