Mechanics of engineering (solids) : comprising statics and kinetics of solids, and the mechanics of the materials of construction, or strength and elasticity of beams, columns, shafts, arches, etc. : for use in technical schools (1911)
Church, Irving P. (Irving Porter), 1851-1931 · New York : Wiley ; London : Chapman & Hall · leaf 439
point beingbetween the verticals of the first two. See Fig. 371. Theloads Pi, etc., are given, with their verticals, while A, p,and B are the three points. Lay oS the load-line, andwith any convenient pole, Oj, construct a force-diagram,then a corresponding preliminary equilibrium polygonbeginning… … Fig. 371. GKAPHICAL STATICS. 419 Dra-w a vertical through p. The H of the required equili-brium polygon must satisfy the proportion H: H^ : •.rs :pm. (See § 338). Hence construct or compute JI fromthe proportion and draw a vertical at distance H fromthe load-line (on the left of the load-line…
Mechanics, Applied · Strength of materials
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
