Mechanics of engineering. Comprising statics and dynamics of solids: and the mechanics of the materials of constructions, or strength and elasticity of beams, columns, arches, shafts, etc (1888)
Church, Irving P[orter], 1851- [from old catalog] · New York, J. Wiley & sons · leaf 431
oint beingbetween the verticals of the first two. See Fig. 371. Theloads Pl9 etc., are given, with their verticals, while A, p,and B are the three points. Lay off the load-line, andwith any convenient pole, Ox, construct a force-diagram,then a corresponding preliminary equilibrium polygonbeginning… … Fig. 371. GEAPHICAL STATICS. 419 Draw a vertical through p. The H of the required equili-brium polygon must satisfy the proportion H: Hx : : rs :pm. (See § 338). Hence construct or compute H fromthe proportion and draw a vertical at distance H fromthe load-line (on the left of the load-line here);…
Mechanics, Applied · Engineering · Strength of materials
