A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)

Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 101

An illustration from A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools, 1918, leaf 101
pends upon theaccuracy of the mould loft^man in getting out hismoulds, in order to conserve the labor of the car-penter in dubbing off and fairing up the scantlingswhile in frame. Moulds.—The moulds are prepared by the mouldloftsman, having plainly marked on them thevarious beveling stations, water… … Figure 47.—Midship Section of SHIP CONSTKUCTION

Shipbuilding

Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
