A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)

Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 120

An illustration from A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools, 1918, leaf 120
Figure 63.—The Finished Timber. MACHINES AND LABOR-SAVING DEVICES 117 s … 118 COURSE IN WOODEN BOAT AND SHIP BUILDING As it is especially hard wood, comparativelylight cuts are made, and each time the carriage isreversed the beveling head is lowered slightly bypower (the dial indicator showing the exact posi-
