A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)

Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 122

An illustration from A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools, 1918, leaf 122
Figure 65.—Faying Knees on a Special Beveling Machine. tion) and another cut is taken. This operation iscontinued until the timber is cut to the desireddepth. The rudder stock is then placed in such aposition that another corner can be cut do%vn inthe same manner. MACHINES AND LABOR-SAVING DEVICES… … 120 COURSE IN WOODEN BOAT AND SHIP BUILDING

Shipbuilding
