ast. Prominent Yard on hand tools to complete the work as shown in theillustration. Every piece of ceiling used in the ship shown inFigure 69 was beveled on this machine, no handtools being used. Even the back of the ceiling atthe turn of the bilge was beveled, using the topbeveling head of the… … MACHINES AND LABOR-SAVING DEVICES 125 about 40 feet, scarfed together with 7-foot scarfs.Each scarf is fastened with eight li/4 bolts set upover clinch rings at both ends. The keel is set upon the keel blocks, wedged and shored in position.The keel shown in Figure 70 probably holds the
