Figure 74.—Frames in Position Ready to Raise. the half frame, through the deadwood, and setup over clinch rings. The cant frames are built up in a similar mannerto the main frames. Figures 78 and 79 show theheels of the cant frames fore and aft of the sameship. In FigTire 79 the flooring is being… … RAISING THE FRAMES 131
